Moving staircase details

Description

The KONE TransitMaster™ 140 moving staircase is a highly durable escalator designed for the most demanding public transportation environments, such as metro stations and airports.

Specifications

  • Operational environment: indoor, semi-outdoor, outdoor
  • Speed: 0.5, 0.65, 0.75 m/s
  • Inclination: 27.3–30º
  • Step width: 1000 mm
  • Vertical rise: up to 35 m

Moving staircase safety

  • Safety is the starting point for every KONE escalator solution. The TransitMaster 140 moving staircase conforms to all local and international safety codes.
  • We provide standard walkalator safety features including comb plate impact device switches and emergency stop buttons for passengers.

Tools and downloads

More Tools And Downloads

Moving staircase options and highlights

Travelmaster 140

Moving staircase eco-efficiency

  • Smart operational modes and an inverter optimize escalator energy consumption under different load conditions
  • Long lasting moving staircase LED lighting is up to 80% more efficient than fluorescent lighting and lasts up to 10 times longer
  • An energy efficient inverter for moving stairs provides smooth speed regulation during standby operation and minimizes energy consumption at full speed
  • The optional regenerative technology for electric stairs cuts power consumption by recycling energy and feeding it back into the system
  • The lubrication-free pallet chain saves oil, reduces chain wear, and decreases fire risk
Travelmaster 140

Moving staircase safety

In addition to the standard moving staircase safety features, we offer optional safety features including

  • Audible alarms and traffic signalization provide clear guidance on escalator travel direction
  • Alarm for travel direction if passengers enter electric stairs in the wrong direction
  • New walkalator traffic signalization solutions and colored step demarcations for extra visual guidance
  • Four-step horizontal section at the top and bottom of the moving staircase makes exit and entry smooth and safe
  • Extensive monitoring options such as KONE Remote Monitoring™ and KONE E-link™ to integrate with your building management systems
Travelmaster 120

Moving staircase design

High quality visual design for electric stairs offers the best possible user experience

  • Innovative and attractive moving staircase lighting solutions that also improve passenger guidance and safety
  • A wide range of walkalator design options to create stunning visual effects and perfectly match your building’s architecture
  • High quality component finishes and a harmonized look and feel throughout the KONE product portfolio"

Contact us for a detailed cost estimate

Escalator solutions

Product name
Type
Segment
Maximum rise
Speed
Inclination
KONE TransVario direct drive available
24/7 Connected Services available
Energy-efficiency class
TravelMaster 110
EscalatorCommercial, retail, hotel, office, multi-use, stadium, medical
13 m
0.5 m/s30°, 35°
TravelMaster™ 110TYesA+++
TravelMaster 115
Inclined autowalkCommercial, retail, hotel, office, multi-use, stadium, medical
7 m
0.5 m/s
10°, 12°

Yes
A+++
TransitMaster 120
EscalatorInfrastructure
15 m
0.5, 0.65, 0.75 m/s27.3°, 30°, 35°TransitMaster™ 120TYes
A+++
TransitMaster 140
EscalatorInfrastructure
35 m
0.5, 0.65, 0.75 m/s27.3°, 30°TransitMaster™ 140TYesA+++
TransitMaster 165
Horizontal autowalkInfrastructure
100 m length
0.5, 0.65, 0.75 m/s
0-6°

YesA+++
